Videocitofonia IP
Videocitofonia IP: per le migliori prestazioni 2
Videocitofonia IP: per le migliori prestazioni 3

IP SYSTEM: for the best performance

The ideal solution for large multi-dwelling projects, capable of guaranteeing high performance, long distances and high video signal quality.

The IP Door Entry System solution is perfect for large residential complexes with a large number of apartments, as it is capable of guaranteeing the best performance, long distances and high video signal quality.
The IP video indoor units, the entrance panels and the guard station feature a modern design, with large touch displays and silver finishes. They have been awarded the prestigious Reddot recognition. The system is designed to be flexible and adaptable to different installations and building needs. The configuration is completed using dedicated software, to define the system type and configure and customise all the parameters.

MAIN FEATURES



  •  Multichannel: for simultaneous conversations (no busy lines);
  •  High definition video quality: up to 1280 x 720;
  •  Technology: IP Protocol;
  •  Cables: FTP and UTP (CAT5 - CAT5E - CAT6) - Fibre optic;
  •  Quick configuration with dedicated software;
  •  Integrations: Onvif IP cameras, lift control, alarm sensors;
  •  Home + Security App: call answering and electrical door lock activation using a smartphone.
Discover the IP video door entry offer
Scopri la nuova offerta di videocitofonia IP
Interface with modern design & intuitive icons
Design moderno e interfacce intuitive 2

Advanced features

3D facial recognition with Liveness sensor. Fingerprint reader. RFID badge and card reader.

10 and 7 inch touch screen

Indoor camera for intercom video calls with other apartments or with the guard station. SOS button and possibility of connecting up to 8 alarm sensors.


Design moderno e interfacce intuitive 3
Video IP

Always aware with the Home + Security App

THE BEST APP FOR A SAFE HOME
Incoming call alert and notifications, motion and people detection, event information and lock management with a simple and intuitive interface.


Home + Security App

Home + Security app screen
Pulsantiere esterne Touch screen
Touch screen entrance panels

Two versions with 10" touch display (374000 - 374002).



-Modern interaction thanks to the large touch display;
-Multiple calling modes; Information and advertising messages with customisable graphics;
-Flush mounted installation with dedicated boxes (to be purchased separately);
-Protection index: IP54;
-Protection index against mechanical impact: IK07.


Pulsantiere esterne Con tastiera
Keypad entrance panels

Two versions with capacitive keyboard and 4.3” display (374001 - 374003).



-More traditional interaction thanks to the keyboard;
-Multiple calling modes;
-Flush mounted installation with dedicated boxes (to be purchased separately);
-Protection index: IP54;
-Protection index against mechanical impact: IK07.


Small entrance panels
Small entrance panels

Three Small versions (374005 – 374004 - 374006).



-With 4.3" display, suitable as an external pushbutton entrance panel for apartment blocks and single apartments;
-With direct call button, ideal as door entrance panel for single apartment;
-Flush mounted installation with dedicated boxes (to be purchased separately);
-Protection index: IP54;
-Protection index against mechanical impact: IK07.


Call the apartment any way you like
Chiamata standard
Standard call

Enter the address sequence of

AREA-BUILDING-RISER-FLOOR-APARTMENT.

Chiamata alfanumerica
Alphanumeric call

Create custom codes with numbers and letters.

Chiamata da rubrica
Address book

With contact list (touch display only).

Access the building in several ways
Riconoscimento facciale
FACE RECOGNITION

3D with dual cameras and Liveness sensor.

Impronta digitale
FINGERPRINT

Fingerprint reader at the entrance panels 374000 and 374001.

Badge e Card RFID
RFID CARD & BADGE

The RFID reader works with programmable cards and coloured badges 348200 …….. 348206.

Codice di accesso
ACCESS CODE

Electrical door lock activation with customisable access code.

Smartphone
SMARTPHONE

Using the Home + Security App, available for download from digital stores.

Videocitofoni touch screen con display da 10 e 7 pollici

PREMIUM Touch screen video indoor units with 10 & 7 inch display

Two versions with indoor camera (373001 – 373002).
Two versions without indoor camera (373003 – 373004).



-Intuitive interface with icons;
-Home page with main functions, favorites, notifications and information;
-Security functions (SOS button and possibility of connecting up to 8 alarm sensors);
-Flashing notification LED;
-Wall installation;
-Versions with indoor camera for Intercom video calls between apartments or guard station.


STANDARD Touch screen video indoor units with 7 inch display

Three different finishes (373005 – 373006 - 373007).



-Black, champagne gold and mirror finishes;
-The black version (373008) works with standard PoE + power supply
-Home page with main functions, favorites, notifications and information;
-Security functions (SOS button and possibility of connecting up to 8 alarm sensors);
-Flashing notification LED;
-Wall installation;



Guard station

Desktop guard station (375000) with high resolution screen.
10" full touch LCD display with icon menu and audio handset. It manages incoming calls from the entrance panels, with the possibility of transferring calls to video indoor units or other guard stations (if present). On the touch display it is possible to view the history of calls and alarms, monitor alarm records and SOS calls from video indoor units, monitor the IP cameras installed in the common areas and the entrance panel cameras.

Guard station
Entrance panels gallery
Indoor units gallery
